LP689EG1

Venus Max – 78kW – 308kW Denso fuel system.

P443EG3, LP443EG4, LP443EG5, LP443EG6, LP665EG1, LP665EG2, LP665EG3, LP665EG4, LP689EG1, LP689EG2, LP689EG3, LP689EG4，LP612EG1, LP612EG2, LP612EG3, LP613EG1, LP613EG2, LP613EG3, LP613EG4.

The VENUS MAX engines produce power in the 78kW to 308kW range. The robust and versatile engine offers Denso high-pressure common rail fuel injection with ECU control. High-flow oil filters, and cyclone air filter system ensure the engine is always in prime condition. The Venus Max range complies with Stage III emission regulations.

• Switchable dual frequency of 1500 or 1800rpm
• Low maintenance – 20,000 hours between overhauls
• Dependable – high-strength cast iron block, easy cold starting down to minus 40ºC, at altitudes up to 4500m
• Denso ECU-controlled common rail injection
• Turbocharged, air-to-air intercooled.

Fixed Speeds
1500 | 1800 r/min

Maximum Power
1500 r/min—185-204kW
1800 r/min—205-226kW

Injection
Denso Common Rail with ECU
